YY-30T-2 Laboratory Hydraulic Press

Equipment Advantages:

1.Automatic temperature control

2. Automatic pressure replenishment

3. Precise temperature control

Technical features:

Parameter	Value
1.Nominal clamping force	0.3MN (30T)
2.Platen (hot plate)specification	L 200×W 200x50mm(thickness), Material: Q235 high-quality carbon structural steel

3.Working layers	2 layers
4.Number of hot plates	3 pieces
5.Distance between hot plates	100mm
6.Hot plate parallelism	≤0.09mm
7.Hot plate surface roughness	Ra≤2.5μm
8.Heating method	Electric heating
9.Heating power per hot plate	600w*4=2.4kw
10.Maximum heating temperature	300℃
11.Temperature control method	Temperature control meter
12.Motor power	3.0KW
13.Plunger stroke/diameter	180mm/Ф160mm,Material:QT500-7
14.Number of oil cylinders	1 set, Material:QT500-7
15.Maximum system pressure	15Mpa
16.Structure form	Four-column type
17.Number/diameter of uprights	4 pieces/Ф55mm, 45#steel
18.Control method	Manual-automatic integrated control
19.Weight	750Kg
20.Customized voltage	440 VAC, 60 Hz
