YY021A Electronic Single Yarn Strength Tester
Used for testing tensile breaking strength and breaking elongation of single yarn or strand such as cotton, wool, silk, hemp, chemical fiber, cord, fishing line, cladded yarn and metal wire. This machine adopts large screen color touch screen display operation.
GB/T3916
1.Color touch screen display, control, Chinese and English interface, menu operation mode;
2.Delete any one of the measured data, test results exported Excel, Word and other documents, easy to connect with the user enterprise management software;
3. Software analysis function: breaking point, breaking point, strain point, elastic deformation, plastic deformation, etc.
4. Safety protection measures: limit, overload, negative force value, overcurrent, overvoltage protection, etc.;
5. Force value calibration: digital code calibration (authorization code);
32-bit MCU, 24-bit AD converter
6. The unique host, computer two-way control technology, so that the test is convenient and fast, the test results are rich and varied (data report, curve, graph, report).
1. Range: 5000CN
2.Sensor load resolution: 1/60000
3. Force measurement accuracy: within the range of 2% ~ 100% of the sensor range for the standard point ±1%
±2% of the standard point in the range of 1% ~ 2% of the sensor range
4.The maximum tensile length stage resolution: 900mm, 0.01mm
5. The clamping distance: 50 ~ 500 free setting, automatic positioning.
6. Stretching speed: 10 ~ 1000mm/min (arbitrary setting)
7. The recovery speed: 10 ~ 1000mm/min (arbitrary setting)
8. Pretension: 0 ~ 150CN
9. Data storage: ≥2000 times (test machine data storage) and can be browsed at any time
10. Power supply: 220V,50HZ,200W
11. Dimensions: 880×350×1700mm (L×W×H)
12. Weight: 60kg
