Flexible Packaging Tester
-
YYP2000-D Ink Mixer
Ink Mixer Introduction:
In order to meet the market demand and meet the higher requirements of customers, the company
has designed and produced a new generation of YYP2000-D mixer. Simple and convenient operation;
Low speed, intermittent agitation on the side of the barrel; Unique mixing paddle design, the ink can be turned and cut during the mixing process, and the ink can be thoroughly mixed within ten minutes; The stirred ink does not heat up. Convenient refuelling bucket, (stainless steel bucket); Mixing speed can be regulated by frequency conversion.
-
YYP30 UV Light Attachment
Technology Parameter
Single phase three lines 220VAC ~ 50Hz
OVERALL POWER
2.2KW
GROSS WEIGHT
100kg
EXTERIOR SIZE
1250L*540W*1100H
ENTER SIZE
50-100mm
CONVEYOR BELT
STAINLESS STEEL
BELT
CONVEYOR BELT SPEED
1-10m/min
UV LAMP
HIGH PRESSURE
MERCURY LAMP
CONVEYOR BELT WIDTH
300mm
COOLING MANNER
AIR COOLING
2KW*1PC
-
YYP225A Printing INK Proofer
Technical Parameters:
Model YYP225A Printing INK Proofer Distributing Mode Automatic Distributing (Distributing Time adjustable) Printing Pressure Printing Pressure can be precisely adjusted according to the thickness of the printing material from outside Major Parts Use Famous Brands of the World Distributing and Printing Speed Distributing and printing speed can be adjusted by shift key according to the properties of ink and paper. Size 525x430x280mm Printing Roller Total Length Total Width:225mm (The maximum spread are is 225mmx210mm Color Strip area and Effective area Color Strip area/Effective area: 45×210/40x200mm (four strips)
Color Strip area and Effective area Color Strip area/ Effective area: 65×210/60x200mm (three strips)
Total Weight About 75 KGS -
YY ST05B Five Point Heat Seal Gradient Tester
Introductions:
The heat seal tester is a necessary laboratory instrument for food enterprises, pharmaceutical enterprises, daily chemical products enterprises, packaging and raw material production enterprises.
Its working conditions simulate the pressure, temperature and time of the packaging line in the packaging process of the packaging line. Through the instrument, the material can be quickly assessed and can be used in the production line after the assessment. Another use is to heat seal the flexible packaging material under the set temperature, pressure and time, so as to conveniently and quickly
find the best heat of the material
Sealing process parameters to meet the requirements of packaging and packaging material manufacturers for the best heat sealing parameters of materials.
II.Meeting Standard:
QB/T 2358（ZBY 28004）、 ASTM F2029、YBB 00122003
-
YYP-PL Trouser Tearing Tensile Strength Tester
- Product Description
The Trouser Tearing Tensile Strength Tester is a basic instrument for testing the physical properties
of materials such as tension, pressure (tensile). The vertical and multi-column structure is adopted,
and the chuck spacing can be arbitrarily set within a certain range. The stretching stroke is large, the running stability is good, and the test accuracy is high. The tensile testing machine is widely used in fiber, plastic, paper, paper board, film and other non-metallic materials top pressure, soft plastic packaging heat sealing strength, tearing, stretching, various puncture, compression, ampoule
breaking force, 180 degrees peel, 90 degrees peel, shear force and other test projects. At the same time, the instrument can measure paper tensile strength, tensile strength, elongation, breaking
length, tensile energy absorption, tensile finger
Number, tensile energy absorption index and other items. This product is suitable for medical, food, pharmaceutical, packaging, paper and other industries.
- Product Features:
- The design method of the imported instrument clamp is adopted to avoid the detection
- error caused by the operator because of the operation technical problems.
- Imported customized high sensitivity load element, imported lead screw to ensure accurate displacement
- Can be arbitrarily selected in the speed range of 5-600mm/min, this function can
- meet the 180° peel, ampoule bottle breaking force, film tension and other samples detection.
- With tensile force, plastic bottle top pressure test, plastic film, paper elongation,
- breaking force, paper breaking length, tensile energy absorption, tensile index,
- tensile energy absorption index and other functions.
- The motor warranty is 3 years, the sensor warranty is 5 years, and the whole machine warranty is 1 year, which is the longest warranty period in China.
- Ultra-long travel and large load (500 kg) structure design and flexible sensor selection facilitate the expansion of multiple test projects.
- Meeting standard:
ISO 6383-1、GB/T 16578、ISO 37、GB 8808、GB/T 1040.1-2006、GB/T 1040.2-2006、
GB/T 1040.3-2006、GB/T 1040.4-2006、GB/T 1040.5-2008、GB/T 4850- 2002、 GB/T 12914-2008、GB/T 17200、 GB/T 16578.1-2008、 GB/T 7122、 GB/T 2790、GB/T 2791、GB/T 2792、
GB/T 17590、 GB 15811、ASTM E4、ASTM D882、ASTM D1938、 ASTM D3330、ASTM F88、 ASTM F904、JIS P8113、 QB/T 2358、 QB/T 1130 、 YBB332002-2015 、YBB00172002-2015 、YBB00152002-2015
-
YYP-A6 Packaging Pressure Tester
Instrument use:
Used to test food package (instant noodle sauce package, ketchup package, salad package,
vegetable package, jam package, cream package, medical package, etc.) need to do static
pressure test. 6 finished sauce packs can be tested at a time. Test item: Observe the
leakage and damage of the sample under fixed pressure and fixed time.
Working principle of instrument:
The device is controlled by touch microcomputer, through adjusting the pressure reducing
valve to make the cylinder reach the expected pressure, the microcomputer timing, control
the reversing of the solenoid valve, control the up and down action of the sample pressure
plate, and observe the sealing condition of the sample under a certain pressure and time.
-
YY M03 Friction Coefficient Tester
- Introduction:
The friction coefficient tester is used to measure the static friction coefficient and dynamic
friction coefficient of paper, wire, plastic film and sheet (or other similar materials), which can
directly solve the smooth and opening property of the film. By measuring the smoothness
of the material, the production quality process indicators such as the opening of the packaging
bag and the packaging speed of the packaging machine can be controlled and adjusted to
meet the requirements of product use.
- Product characteristics
1. Imported microcomputer control technology, open structure, friendly man-machine interface operation, easy to use
2. Precision screw drive, stainless steel panel, high-quality stainless steel guide rail and reasonable design structure, to ensure the stability and durability of the instrument
3. American high precision force sensor, measuring accuracy is better than 0.5
4. Precision differential motor drive, more stable transmission, lower noise, more accurate positioning, better repeatability of test results
56,500 color TFT LCD screen, Chinese, real-time curve display, automatic measurement, with the test data statistical processing function
6. High-speed micro printer printing output, printing fast, low noise, no need to replace the ribbon, easy to replace the paper roll
7. The sliding block operation device is adopted and the sensor is stressed at a fixed point to effectively avoid the error caused by motion vibration of the sensor
8. Dynamic and static friction coefficients are displayed digitally in real time, and the slider stroke can be preset and has a wider adjustment range
9. National standard, American standard, free mode is optional
10. Built-in special calibration program, easy to measure, calibration department (third party) to calibrate the instrument
11. It has the advantages of advanced technology, compact structure, reasonable design, complete functions, reliable performance and easy operation.
-
YYP108-10A Film Tearing Tester
Design criteria:
1.ISO 6383-1 plastics. Determination of tear resistance of films and sheets. Part 1: Split pants type tearing method
2.ISO 6383-2 plastics. Films and sheets – Determination of tear resistance. Part 2: Elmando Method
3.ASTM D1922 Standard test Method for Determination of Resistance to Expansion Tearing of plastic films and sheets by the pendulum Method
4.GB/T 16578-1 Plastic films and sheets – Determination of tear resistance – Part 1: trouser tear method
5.ISO 6383-1-1983, ISO 6383-2-1983, ISO 1974, GB/T16578.2-2009, GB/T 455, ASTM D1922, ASTM D1424, ASTM D689, TAPPI T414
Product Features:
1. The system is controlled by computer and adopts automatic and electronic measurement method, which is convenient for users to carry out test operation quickly and conveniently
2. Pneumatic sample clamping and pendulum release effectively avoid systematic errors caused by human factors
3. The computer level adjustment auxiliary system can ensure that the instrument is always in the best test state
4. Equipped with multiple groups of pendulum capacity to meet different test needs of users
5. Professional software supports data output of various test units
6. Standard RS232 interface to facilitate external access and data transmission of the system
-
YYP-R2 Heat Shrink Tester
Instrument Introduction:
The heat shrink tester is suitable for testing the heat shrink performance of materials, which can
be used for plastic film substrate (PVC film, POF film, PE film, PET film, OPS film and other heat
shrink films), flexible packaging composite film, PVC polyvinyl chloride hard sheet, solar cell
backplane and other materials with heat shrink performance.
Instrument characteristics:
1. Microcomputer control, PVC menu type operation interface
2. Humanized design, easy and fast operation
3. High-precision circuit processing technology, accurate and reliable test
4. Liquid non-volatile medium heating, heating range is wide
5. Digital P.I.D temperature control monitoring technology can not only quickly reach the set temperature, but also effectively avoid temperature fluctuations
6. Automatic timing function to ensure test accuracy
7. Equipped with standard sample holding film grid to ensure that the sample is stable without interference from temperature
8. Compact structure design, light and easy to carry
-
YY112N Gas Chromatograph(GC)
Technical Features:
1.Standard PC control software, built-in chromatographic workstation, achieve PC side reverse control
and touch screen synchronous bidirectional control.
2. 7-inch color touch screen, carrier/hydrogen/air channel flow (pressure) digital display.
3. Gas shortage alarm protection function; Heating control protection function (when opening the doorof the column box, the motor of the column box fan and the heating system will shut down automatically).
4. Split flow/split ratio can be automatically controlled to save carrier gas.
5. Configure automatic sampler installation and positioning interface to match automatic sampler ofvarious specifications.
6.The multi-core, 32-bit embedded hardware system ensures the reliable operation of the instrument.
7. One-button start function, with 20 groups of sample test mode memory function.
8. Using logarithmic amplifier, detection signal no cut-off value, good peak shape, extensible synchronous external trigger function, can be started by external signals (automatic sampler, thermal analyzer, etc.) atthe same time the host and workstation.
9. It has perfect system self-check function and fault automatic identification function.
10. With 8 external event extension function interface, can be selected with various function control valves,and according to their own set time sequence work.
11. RS232 communication port and LAM network port, and the configuration of data acquisition card. -
YY311-AE3 Water Vapor Permeability Tester (Electrolytic method)
Testing application
Basic application
Films
Water vapor permeability test of various plastic film, plastic composite film, paper-plastic composite film, co-extrusion film, aluminized film, aluminum foil composite film, glass fiber aluminum foil composite film and other membrane materials. Sheets
Water vapor permeability test of PP sheet, PVC sheet, PVDC sheet, metal foil sheet, film sheet, silicon sheet and other sheet materials. Paper, board and composite materials
Water vapor permeability test of cigarette coated paper, paper aluminum – plastic composite sheet and other paper and board. Packaging
Water vapor permeability test of bottles, Coke bottles, peanut oil drums, Tetra Pak packaging, vacuum packaging bags, three-piece cans, cosmetics packaging, toothpaste hose, jelly cups, yogurt cups and other plastic, rubber, paper, paper composite, glass, metal materials of bottles, bags, cans, boxes, barrels. Expanding applicatoin
Package seal
Water vapor permeability test of various vessel caps. LCD
Water vapor permeability test of LCD screen and related films. Solar energy backplane
Water vapor permeability test of solar backplane and related materials. Tubes
Water vapor permeability test of PPR and other tubes. Pharmaceutical blister
Water vapor permeability test of pharmaceutical blisters. Sterile wound protection film, medical plaster patch
Water vapor permeability test of sterile wound protection films and medical plaster patches. Cellpacking
Water vapor permeability test of cellpacking. -
YY310-D3 Oxygen Permeability Tester (Coulometry)
It is suitable for oxygen and water vapor permeability of high barrier materials such as plastic film, aluminum foil plastic film, waterproof material and metal foil. Expandable test bottles, bags and
other containers are available.
